2025 GAC AION Y Plus 510 Smart Luxury Edition

Contact for details

Launch: 2025-06-03136PsOrigin: ChinaTransmission: Single-speed EV TransmissionFuel: EVBody Type: SUV

Sales ManagerDaisy

Chat With UsWhatsApp

Overview

Basic Information

Manufacturer:GAC Aion

Vehicle Class:Compact SUV

Energy Type:Battery Electric

Launch Date:2025-06-03

Max Power (kW):100

Max Torque (N·m):176

Electric Motor (Ps):136

L×W×H (mm):4535*1870*1650

Top Speed (km/h):150

CLTC Electric Range (km):510

Equivalent Fuel Consumption (L/100km):1.5

Vehicle Warranty:4 years or 150,000 km

Curb Weight (kg):1720

Max Gross Weight (kg):2180

Body

Length (mm):4535

Width (mm):1870

Height (mm):1650

Wheelbase (mm):2750

Front Track (mm):1600

Rear Track (mm):1600

Loaded Ground Clearance (mm):150

Approach Angle (°):18

Departure Angle (°):27

Min Turning Radius (m):5.5

Body Structure:SUV

Door Opening Type:Conventional Doors

Doors:5

Seats:5

Trunk Volume (L):405

Electric Motor

Front Motor Brand:Suzhou Inovance

Front Motor Model:TZ180XS130

Motor Type:Permanent Magnet / Synchronous

Total Motor Power (kW):100

Total Motor Horsepower (Ps):136

Total Motor Torque (N·m):176

Front Motor Max Power (kW):100

Front Motor Max Torque (N·m):176

Drive Motors:Single Motor

Motor Layout:Front-mounted

EV System Warranty:Lifetime warranty for powertrain (for first owner, max 30,000 km/year)

Battery & Charging

Battery Type:LFP Battery

Cell Brand:YinPai Battery, GAC Times

Battery Technology:Bulletproof Battery

Battery Cooling:Liquid Cooling

CLTC Electric Range (km):510

Battery Capacity (kWh):58.4/58.9

Power Consumption (kWh/100km):12.9

Fast Charging:Supported

AC Charge Port Location:Right Front Side

DC Charge Port Location:Left Front Side

Transmission

Abbreviation:Single-speed EV Transmission

Gears:1

Transmission Type:Fixed Gear Ratio Transmission

Chassis & Steering

Drive Type:Front-wheel Drive

Front Suspension:MacPherson Independent Suspension

Rear Suspension:Torsion Beam Non-independent Suspension

Steering Assist:Electric Power Steering

Body Structure:Unibody

Wheels & Brakes

Front Brakes:Ventilated Disc

Rear Brakes:Disc

Parking Brake:Electronic Parking Brake

Front Tires:215/55 R17, 215/50 R18 (¥2000), 225/45 R19 (¥4500)

Rear Tires:215/55 R17, 225/45 R19 (¥4500), 215/50 R18 (¥2000)

Spare Tire:Temporary Spare Tire (¥1000)

Passive Safety

Front Airbags:Driver/Passenger

Active Safety

ABS:Standard

Brake Force Distribution (EBD/CBC):Standard

Brake Assist (EBA/BAS/BA):Standard

Traction Control (ASR/TCS/TRC):Standard

Stability Control (ESC/ESP/DSC):Standard

Tire Pressure Monitoring:Tire Pressure Warning

Seat Belt Reminder:All Seats

ISOFIX Child Seat Anchors:Standard

Autonomous Emergency Braking:Standard

Forward Collision Warning:Forward Collision Warning (Low Speed)

Driving Dynamics

Drive Mode Select:Sport, Eco, Standard/Comfort

Auto Hold:Standard

Hill Start Assist:Standard

Driving Hardware

Front/Rear Parking Sensors:Front-/Rear

Driver Assistance Camera:360° Panoramic Camera

Transparent Chassis / 540° View:Standard

Front Perception Camera:Mono Camera

Cameras:5

Ultrasonic Sensors:3

Driving Features

Cruise Control:Full-speed Adaptive Cruise Control

Driver Assistance Level:L2

Satellite Navigation:Standard

Live Traffic Info:Standard

Lane Keeping Assist:Standard

Auto Parking Assist:Standard

Exterior

Wheel Material:Alloy

Central Locking:Standard

Key Type:Remote Key

Keyless Start:Standard

Keyless Entry:Front Row

Exterior Lighting

Low Beam:LED

High Beam:LED

LED Daytime Running Lights:Standard

Auto Headlights:Standard

Headlight Level Adjustment:Standard

Headlight Delay Off:Standard

Sunroof & Glass

Power Windows:Front/Rear

One-touch Windows:All

Anti-pinch Windows:Standard

Rain-sensing Wipers:Rain-sensing

Exterior Mirrors

Mirror Features:Electric Adjustment, Electric Folding, Heating, Auto-folding on Lock

Power Mirror Adjustment:Standard

Power Folding:Standard

Heated Mirrors:Standard

Auto Fold on Lock:Standard

Connectivity & Intelligence

Center Display:Touchscreen LCD

Center Screen Size:14.6 inches

Infotainment OS:ADiGO

Bluetooth / Hands-free:Standard

Phone Connectivity:HUAWEI HiCar, Carlink

Voice Control:Multimedia, Navigation, Phone, Air Conditioning

Voice Zone Recognition:Dual-zone

Continuous Voice Recognition:Standard

See-and-say:Standard

Steering & Interior Mirror

Steering Wheel Material:Leather

Steering Adjustment:Manual Tilt Adjustment

Shift Type:Electronic Column-mounted Shifter

Multifunction Steering Wheel:Standard

Trip Computer Display:Color

Digital Instrument Cluster:Standard

Cluster Screen Size:10.25 inches

Interior Mirror Features:Manual Anti-glare

In-cabin Charging

Media / Charging Ports:USB

USB / Type-C Ports:Front: 1, Rear: 1

Seats

Seat Material:Synthetic Leather

Driver Seat Adjustment:Fore-aft, Backrest, Height (2-way)

Passenger Seat Adjustment:Fore-aft, Backrest

Power Front Seats:Driver/Passenger-

Front Seat Functions:Heating (Driver Only), Ventilation (Driver Only)

Rear Seat Fold:Split Folding

Front/Rear Armrests:Front/Rear-

Audio & Interior Lighting

Speakers:6

Climate & Refrigerator

Climate Control Type:Automatic Air Conditioning

Heat Pump A/C:Standard

Rear Vents:Standard

PM2.5 Filter:Standard

Colors

Exterior Colors:black/white/gray

Interior Colors:black/white/gray
